Table 4-5 Data plan for configuring the ATM PWE3 (MPLS-based)
Item Data
MPLS LSR ID: 5.5.5.5
Global MPLS TE: enabled
MPLS Layer 2 VPN: enabled
VLAN MPLS RSVP-TE: enabled
VLAN Standard VLAN for MPLS forwarding: 300
MPLS address of the VLAN interface: 192.168.2.20
Upstream port: 0/19/1
PW parameters PW ID: 20
Peer IP address: 7.7.7.7
PW type: ATM Nto1 VCC
PW in VPI/VCI: 0/35
PW out VPI/VCI: 8/35
PW type: static
Control word: enabled
PW out port: 8450
PW in port: 8460
Tunnel
Tunnel ID: 20; tunnel interface ID: 20
Encapsulation protocol of the tunnel interface at the data link
layer: MPLS TE
Tunnel signaling protocol: RSVP-TE
ATM service port Port: 0/2/0
Emulation SVLAN: 3001
VPI/VCI: 0/35
OSPF OSPF process ID: 200; OSPF area ID: 1
Enable MPLS TE for the OSPF area
PWE3 gateway LSR ID: 7.7.7.7
Procedure
Step 1 Configure a VLAN and add an upstream port to the VLAN.
Create upstream VLAN 300 and add upstream port 0/19/1 to VLAN 300.
huawei(config)#vlan 300 standard
huawei(config)#port vlan 300 0/19 1
Step 2 Enable MPLS.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
4 Configuration Example of the Private Line Service
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
410
