Figure 6-3 Networking for the VPLS enterprise private line service

VPLS

VPLS PW

Branch A

Branch B

Branch C

PW2

(Master)

PW3

(Slave)

PE3 (CX600)

PE2 (CX600)

OLT/MSAN

PE1

PE4

PW1

PW4

Prerequisite

QinQ traffic streams have been configured on PE1-PE4 for the private line service of different

branch offices.

NOTE

To configure the Ethernet-based enterprise private line service, you must configure QinQ VLAN-based Ethernet

traffic streams on PE1-PE4, and perform corresponding configurations on routers for branch offices of the

enterprise. The configurations are the same as those for common QinQ VLAN private line service, which are

not described here.

Data Plan

Table 6-4 provides the key data plan for the OLT/MSAN (MA5600T/MA5603T/MA5608T).

SmartAX MA5600T/MA5603T/MA5608T Multi-service

Access Module

Commissioning and Configuration Guide 6 Configuration Example of VPLS

Issue 01 (2014-04-30) Huawei Proprietary and Confidential

500
