Huawei SmartAX MA5608T User Manual

Table 6-4 Key data plan
Confi
gurati
on
Item
Data Remarks Requirement on PE1-PE4
MPLS
l LSR ID:
10.10.10.10
l VLAN: 4001
MPLS must be enabled at
three layers.
l MPLS must be enabled
globally.
l MPLS must be enabled
for VLAN.
l MPLS must be enabled at
VLAN interfaces.
The LSR ID must be unique
on the entire network and
MPLS must be enabled.
LDP MPLS LDP is
enabled.
MPLS LDP must be enabled
at three layers.
l MPLS LDP must be
enabled globally.
l MPLS LDP must be
enabled at VLAN
interfaces.
MPLS LDP is enabled. The
remote LDP session to the
MA5600T/MA5603T/
MA5608T is configured on
PE1-PE4.
Routin
g
protoc
ol
The Open Shortest
Path First (OSPF)
protocol is used.
Ensure that the Layer 3
interfaces on the MA5600T/
MA5603T/MA5608T and
those on PE1-PE4 can ping
each other.
Layer 3 interfaces and routes
are configured on PE1-PE4.
Ensure that the Layer 3
interfaces and LSR IDs on
PE1-PE4 and those on the
MA5600T/MA5603T/
MA5608T can ping each
other.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 6 Configuration Example of VPLS
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
501

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
