Confi
gurati
on
Item
Data Remarks Requirement on PE1-PE4
VPLS
PW
l PW ID: 1, 2, 3,
4
l Service type:
vpls
l Encapsulation
type: ethernet
tagged
l The control
word is enabled.
PW protection
group:
l PW ID: 2, 3
l Working mode:
master-slave
l The dual
receiving
function is
enabled for
PWs.
On the OLT/MSAN, PW1
and PW4 are created for PE1
and PE4 respectively,
and PW2 and PW3 are
created for PE2 and PE3
respectively. PW2 and PW3
back up each other.
The LDP VPLS is supported,
and VPLS PWs to the
MA5600T/MA5603T/
MA5608T are configured on
PE1-PE4, and attributes of
PWs are consistent with those
on the MA5600T/MA5603T/
MA5608T.
VSI
l PW1-PW4 are
bound to VSI.
l Binding mode
of PW 1 and PW
4: spoke
l VLAN 100 of
the private line
service is bound
to VSI.
VSI binds VLAN and PW to
map VLAN to the VPLS
domain, so that packets for
the enterprise private line
service can be broadcast in
the VPLS domain.
VSI is configured on PE1-
PE4 and the VSI ID must bind
the corresponding PW.
Procedure
Step 1 Configure the basic MPLS.
1. Configure a loopback interface.
Set the ID of the loopback interface to 0 and its IP address to 10.10.10.10/32.
huawei(config)#interface loopback 0
huawei(config-if-loopback0)#ip address 10.10.10.10 32
huawei(config-if-loopback0)#quit
2. Configure the MPLS LSR-ID. Use the IP address of loopback interface 0 as the LSR ID.
huawei(config)#mpls lsr-id 10.10.10.10
3. Enable MPLS globally.
Trigger LDP by the IP address of the host to set up an LSP.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
6 Configuration Example of VPLS
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
502
