Table 7-1 provides the service and the data plan for the example subtended network of the
MA5600T in Figure 7-1.
Table 7-1 Data plan for the example subtended network
Item MA5600T-1 MA5600T-2 MA5600T-3 MA5600T-4
Service
l ADSL2+
service
l SHDSL
service
l GPON
service
l POTS service
l QinQ private
line service
(for the
private line
interconnecti
on
withMA5600
T-4)
l Multicast
service
l ADSL2+
service
l SHDSL
service
l POTS service
l Stacking
wholesale
service
l Triple play
service
l ADSL2+
service
l SHDSL
service
l GPON service
l POTS service
l Multicast
service
l VDSL2
service
l QinQ private
line service
(for the
private line
interconnectio
n
withMA5600
T-1)
Inband
NMS
address
10.10.1.2
255.255.255.0
Gateway:
10.10.1.1/24
10.10.1.3
255.255.255.0
Gateway:
10.10.1.1/24
10.10.1.4
255.255.255.0
Gateway:
10.10.1.1/24
10.10.1.5
255.255.255.0
Gateway:
10.10.1.1/24
GE port
of the
GIU
board
Upstream: 0/19/0
Subtending:
0/19/1
Upstream: 0/19/0
Subtending:
0/19/1
Upstream: 0/19/0 Upstream: 0/19/0
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 7 Example: Subtending Networking
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
509

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
