– Set VLAN ID to 300. (The VLAN ID of the ONT must be the same as the
user-side VLAN ID configured on the OLT.)
– Set 802.1p to 5.
– Set IP Acquisition Mode to DHCP.
c. Click Apply.
3. Configure parameters for the SIP-based voice interface.
a. Choose Voice > VoIP Basic Configuration.
b. In the Basic Interface Parameters(SIP) window, configure the parameters as
follows:
– Set Address of the Primary Proxy Server to 200.200.200.200.
– Set Home Domain to huawei.com.
– Set Region to China.
– Set Signaling Port to 1_VOIP_R_VID_300.
NOTE
l The parameters of the SIP-based voice interface must be consistent with the corresponding
configuration on the softswitch.
l If dual-homing is configured, Address of the Standby Proxy Server must be configured.
l If Signaling Port is empty, the parameter value is the same as Media Port. If the upper-
layer network requires isolation of media streams from signaling streams, create different
traffic streams for the media streams and signaling streams on the OLT, create different
WAN ports on the ONT, and bind the created WAN ports to Media Port and Signaling
Port. When the packet is forwarded from two WAN ports, the configured VLAN is carried
by default.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
605
