Item Data Remarks
Multicast
emulation
parameters
Multicast service flow ID: 1
MVLAN: 1000
IP address of the multicast
program: 224.1.1.10
-
Procedure
l Verify the Internet access service using PPPoE dialup emulation.
1. In the xPON board mode, run the pppoe simulate start command to start a PPPoE
dialup emulation test. The following test uses GPON as an example:
huawei(config)#interface gpon 0/1
huawei(config-if-gpon-0/1)#pppoe simulate start
{ portid<U><0,7> }:0
{ ontid<U><0,127> }:1
{ eth<K>|untagged<K>|vlanid<U><0,4095> }:eth
{ ont-portid<U><1,8> }:4
{ untagged<K>|vlanid<U><0,4095> }:100
{ priority<U><0,7>|user-name<K> }:user-name
{ username<S><Length 1-64> }:test@huawei
{ user-password<K> }:user-password
{ password<S><Length 1-64> }:test
{ authentication-mode<K> }:authentication-mode
{ protocol<E><chap,pap> }:chap
Command:
pppoe simulate start 0 1 eth 4 100 user-name test@huawei user-
password
test authentication-mode chap
huawei(config-if-gpon-0/1)#
----------------------------------
ONT PPPoE Test Result
----------------------------------
F/S/P : 0/1/0
ONT-ID : 1
ONT ETH Port ID : 4
ONT Vlan ID : 100
Vlan Priority : -
Emluator result : Success
Session ID : 18814
User IP : 192.168.100.101
Gateway IP : 192.168.100.1
----------------------------------
l Troubleshooting methods for the Internet access service
1. Check whether configurations are complete on the OLT.
– Run the display ont info command to query the ONT status to check whether the
ONT is registered successfully.
– Run the display service-port command to check whether the Internet access
service flow is configured and whether the inner VLAN ID of the service flow is
consistent with that in the data plan.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
626
