Control flag : active //Indicates that the ONT is
activated.
Run state : online //Indicates that the ONT goes online
successfully.
Config state : normal //Indicates that the configuration state
of the ONT is normal.
Match state : match //Indicates that the capability profile
bound to the ONT is consistent with the actual capability of the ONT.
...//The rest of the response information is omitted.
When Config state is failed, Run state is offline, or Match state is mismatch:
– If Control flag is deactive, run the ont active command in GPON mode to activate
the ONU.
– If Run state is offline, a physical line may be disconnected or the optical module
may be damaged. Check the line and the optical module.
– If Config state is failed, the configured ONU capability exceeds the actual ONU
capability. In this case, run the display ont failed-configuration command in the
diagnose mode to check the failed configuration item and the failure cause. Then,
rectify the fault accordingly.
NOTE
If the ONT only supports 4 queues, the priority-queue parameter of the gem add command is
invalid when the priority-queue value is set to 4-7. Consequently Config state is failed.
– If the ONU does not match, that is, Match state is mismatch, the port types and
number of ports undermatch the actual port types and number of ports supported
by the ONU. In this case, run the display ont capability command to query the
actual capability of the ONU, and then select one of the following modes to modify
the ONU configuration:
– Create a proper ONU profile according to the actual capability of the ONU,
and then run the ont modify command to modify the configuration data of the
ONU.
– Modify the ONU profile according to the actual capability of the ONU and save
the modification. Then, the ONU automatically recovers the configuration
successfully.
4. Configure the Internet access service.
a. Create an S-VLAN and add an upstream port to it.
The VlAN ID is 100, and the VLAN type is smart. Add upstream port 0/19/0 to
smart VLAN 100.
huawei(config)#vlan 100 smart
huawei(config)#port vlan 100 0/19 0
b. Configure a traffic profile.
Run the display traffic table ip command to query existing traffic profiles in
the system. If the traffic profiles existing in the system do not meet the
requirements, you need to run the traffic table ip command to add a traffic
profile.
Set the profile ID to 8, the CIR to 4 Mbit/s, and the priority to 1. In addition,
configure the scheduling mode so that packets are scheduled according to their
priorities.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
713
