Data plan
Item Data Remarks
PPPoE
dialup
emulation
parameters
PPPoE user name: test@huawei
Password: test
The user name, password, and
authentication mode for the emulation test
must be configured on the BRAS. The
entered user name, password, and
authentication mode must be consistent
with those configured on the BRAS.
Multicast
emulation
parameters
Multicast service flow ID: 1
MVLAN: 1000
IP address of the multicast
program: 224.1.1.10
-
Procedure
l Verify the Internet access service using PPPoE dialup emulation.
1. In the xPON board mode, run the pppoe simulate start command to start a PPPoE
dialup emulation test. The following test uses GPON as an example:
huawei(config)#interface gpon 0/1
huawei(config-if-gpon-0/1)#pppoe simulate start
{ portid<U><0,7> }:0
{ ontid<U><0,127> }:1
{ eth<K>|untagged<K>|vdsl|vlanid<U><0,4095> }:vdsl
{ ont-portid<U><1,8> }:1
{ untagged<K>|vlanid<U><0,4095> }:100
{ priority<U><0,7>|user-name<K> }:user-name
{ username<S><Length 1-64> }:test@huawei
{ user-password<K> }:user-password
{ password<S><Length 1-64> }:test
{ authentication-mode<K> }:authentication-mode
{ protocol<E><chap,pap> }:chap
Command:
pppoe simulate start 0 1 vdsl 1 100 user-name test@huawei user-
password
test authentication-mode chap
huawei(config-if-gpon-0/1)#
----------------------------------
ONT PPPoE Test Result
----------------------------------
F/S/P : 0/1/0
ONT-ID : 1
ONT VDSL Port ID : 1
ONT Vlan ID : 100
Vlan Priority : -
Emluator result : Success
----------------------------------
l Troubleshooting methods for the Internet access service
1. Check whether configurations are complete on the OLT.
– Run the display ont info command to query the ONU status to check whether the
ONU is registered successfully.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
811
