– Run the display service-port command to check whether the Internet access
service flow is configured and whether the inner VLAN ID of the service flow is
consistent with that in the data plan.
– If a native VLAN is configured for the VDSL2 port on the ONU, run the display
ont port attribute command in the xPON board mode to check whether the native
VLAN is correct.
2. Check the upstream and downstream ports by checking the MAC address learning
status.
a. Run the display mac-address vlan command to check the MAC address learning
status of the Internet service VLAN.
– If the upstream port does not learn a MAC address, check the network
connections between the upstream port and upper-layer devices and check
the configurations of upper-layer devices.
– If the downstream port does not learn a MAC address, check whether the
ONU is activated, whether the PC is connected to the right port on the ONU,
and whether the PC is working properly.
b. Run the display ont-learned-mac command to check whether the ONU
connecting to the PON port learned any MAC addresses.
If not, check whether the ONU properly connects to the PC or home gateway
(HGW).
l Verify the multicast service using multicast emulation.
1. Run the igmp static-join command to simulate a multicast user to order a multicast
program.
huawei(config)#btv
huawei(config-btv)#igmp static-join service-port 1 ip 224.1.1.10 vlan 1000
NOTE
If the multicast program is obtained dynamically, igmp static-join can be executed successfully
only when the range for obtaining the dynamic program is set.
2. Run the display igmp user command to query the status of the multicast user.
huawei(config-btv)#display igmp user service-port 1
User : 0/1/0/1
State : online
Authentication : no-auth
Quick leave : MAC-based
IGMP flow ID : 1
Video flow ID : 1
Log switch : enable
Bind profiles : -
IGMP version : IGMP v3
Current version : IGMP v3
Current IGMP IPv6 version : IGMP IPv6 v2
Available programs : 8
Global leave : disable
User max bandwidth : no-limit
Used bandwidth(kbps) : 0
Used bandwidth
to max bandwidth(%) : -
Total video bandwidth : -
Mcast video bandwidth : -
Active program list
-------------------------------------------------------------------------
--
Program name VLAN IP/MAC State Start time
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
812
