Item Data Description
Policy for controlling
frequent online and
offline on ports
no-limit -
Vectoring group Group ID: 1 All ports are added to the default
vectoring group 1.
Vectoring profile For the MA5623A/MA5616:
Profile ID: 1 The upstream/
downstream crosstalk
cancelation function in default
Profile 1 are as follows:
l Upstream crosstalk
cancelation: enable
l Downstream crosstalk
cancelation: enable
-
For MA5603T:
l Profile name: huawei
l Upstream crosstalk
cancelation: enable
l Downstream crosstalk
cancelation: enable
l The port to which a vectoring
profile is bound: all ports on
the0/1 board.
NOTE
The Vectoring is configured on the ONU, and the configuration between the MA5623A/MA5616 and
MA5603T is a little different, Here gives the configuring steps of MA5623A/MA5616 and MA5603T
respectively.
Procedure
l Configuration procedure for the MA5623A/MA5616:
1. Log in to the ONU remotely and start the configuration.
By default, the user name is root and the password is mduadmin.
2. Globally configure the band plan type.
huawei(config)#xdsl vectoring bandplan-type 998ade us0-type type-a
3. Configure the policy for activating a vectoring legacy CPE.
huawei(config)#xdsl vectoring legacy-cpe activate-policy no-limit
4. Configure the policy for controlling frequent online and offline on ports.
huawei(config)#xdsl frequent-retrain-control 0/1/0 control-policy no-limit
5. Enable global vectoring.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
907
