F.5Part. N. 8000 H1344 (10-2009)
ENGINE DISASSEMBLY
Loosen the cam-chain tensioner (10 mm wrench) then remove the two fastening
screws (8 mm wrench) and the cam-chain tensioner assembly.
Remove the eight fastening screws of the camshaft clamps (5 mm wrench) and
the clamps themselves using these same screws.
Remove the lubricating tube.
Remove the camshafts.
