I.27
Part. N. 8000 H1344 (10-2009)
FRONT SUSPENSION
INSTRUCTIONS FOR USE OF Ø48 Upside-Down
(MODELS TC 450 - TXC 450/510)
GENERAL
This fork is based on a multivalve damping system allows rebound and compres-
sion to be controlled and adjusted, it also has a spring for static load.
Each fork’s leg is provided with external adjusters for the compression and
the slider inner air bleed.
SPRING TABLE
The static load of the fork is determined by the spring: by changing either spring
features or pre-load sleeve length a different suspension behavior is obtained
without changing the hydraulic features. The following table describes the springs
available as spare parts.
COSTANT K (N/mm) CODE
4.8 8000 H2685
