I.28
Part. N. 8000 H1344 (10-2009)
FRONT SUSPENSION
Loosen the upper cap of each stem guide.
(N.B.: It’s a good rule to loosen the caps slightly before removing the stems of
the motorcycle).
Remove the oil from the shock absorber unit.
Lock the wheel pin support into place and loosen the adjusting screw.
Push the inner tube downwards.
Position the tool illustrated between the wheel pin support and the nut of the
cartridge unit.
Hold the nut in place with a spanner and remove the adjusting screw.
