BRAKING DOWN THE FORK LEG – SLIDER AND REMOVING THE OIL
SEALS


-
ments you will have to pull hard. With this operation the oil seal ( 10 ), the spring
cup ( 9 ) and the bottom guide bushing ( 8 ) will be removed from the slider.



the stop ring ( 11 ) and the dust seal ( 12 ) from the stanchion tube.
WARNING
The old oil seals and dust seals must not be used again.
Paragraph 4.9 describes the procedure for assembling the seal elements
and re-assembling the fork leg -slider.
