Husqvarna TE 310 - Crankcase Disassembly

F.21Part. N. 8000 H1344 (10-2009)
ENGINE DISASSEMBLY
Crankcase disassembly
Remove the circlip from the secondary shaft (R.H.S.).
Remove the drive sprocket circlip and the drive sprocket from the secondary
shaft.
Extract the drive sprocket spacer.
Remove the twelve screws from the L.H. crankcase side (8 mm wrench).
