OVERHAULING AND MODIFYING THE CARTRIDGE AND BOTTOM VALVE
SETTING
CARTRIDGE OVERHAULING (REBOUND BRAKING)
Dismantling


nut.

( 37 ), the piston ( 36 ) complete with the segment ( 35 ), the washer ( 34 ) and
the spring ( 33 ), following this order.
Assembling:
The washers ( 37 ) and the piston ( 36 ) are the ones causing the rebound
braking. It is possible, if needed, to modify the fork’s behaviour during
the rebound phase, by replacing the washers ( 37 ) and the piston ( 36 )
with other components having different characteristics.
WARNING
Only use original Marzocchi washers and pistons, do not modify the
components.


with the segment (35), the washer or the washers stack regulating the rebound
(37), following this order.
