I.7
Part. N. 8000 H1344 (10-2009)
FRONT SUSPENSION
INSTRUCTIONS FOR USE OF Ø50USD FORK (TE 310 EU-SMR)
GENERAL
Telehydraulic upside down fork, with advanced axle.
This fork is based on a multivalve damping system and spring for static load.
The compression hydraulic damping is made through a special valve located
in each fork’s leg lower area, whereas the rebound hydraulic damping is made
through a cartridge located inside each stanchion. Each fork’s leg is provided
with external adjusters for the compression and extension adjustment. On both
Stanchion tubes: Made of special, chromed, high- resistance steel, with a special
hardening surface treatment ( TIN ).
Sliders: Made of CNC aluminium alloy, anodised and
polished inside.
Seals: Computer designed seal rings guarantee the beast seal under compression
and the minimum friction during rebound.
Springs: Made of steel, they are available in different stiffness ( K ). For more
detailed information please refer to Table 4 - Springs.
Oil: MARZOCCHI with special formula. It eliminates the formation of foam and
keeps the viscosity characteristics unchanged in any working
condition; free from static friction.
For very cool climate use oil MARZOCCHI SAE 5 Art. 55 00 03.
SPRING TABLE
The static load of the fork is determined by the spring, positioned at the top of
each leg: by changing either spring features or pre-load sleeve length a different
suspension behavior is obtained without changing the hydraulic features. The
following table describes the “spring+pipe” kit available as spare part.
COSTANT K (N/mm) CODE
4,5 (TE) 8000 B1713
5,0 (SMR) 8000 A7608
