Husqvarna TE 310 - Removing the Front Fork

I.4
Part. N. 8000 H1344 (10-2009)
FRONT SUSPENSION
Removing the front fork
Take note of measure “A” which must be restored when reassembling. Set a sup-
port under the engine to lift the front wheel from the ground, working as follows:
-remove,on the L.H. side, the screws (1) , the brake hose and the instrument
cable clamp (TE-SMR) on the fork tube guard;
- remove the six screws (2) and the fork tube guards;
- remove the brake caliper from the L.H. fork tube by unscrewing the two fasten-
ing screws (3);
- remove the front wheel following the instructions on page Y.6;
- unloose the screws (4) fastening each fork slider to the steering head and
steering base;
