M.33Part. N. 8000 H1344 (10-2009)
ELECTRIC SYSTEM, DIGITAL INSTRUMENT
NOTES
CONNECTORS
• When a connector is connected, check that it clicks into position.
• Check the connector for corrosion, dirt or a broken cover.
COUPLINGS
• Block couplings – ensure that the block is released before disconnecting it to
push it completely home when connecting it.
• When disconnecting a coupling, ensure that the body of the coupling is gripped
and do not pull it apart by the leads.
• Check that the terminals of the couplings are not slack or bent.
• Check that the terminals are not corroded or dirty.
