Husqvarna TE 310 - Carburettor Checking

G.23Part. N. 8000 H1344 (10-2009)
ENGINE OVERHAULING
Carburettor checking
1. Inspect:
- Carburetor body
Contamination: Clean
NOTE:
- Use a petroleum based solvent for cleaning. Blow out all pas-
sages and jets with compressed air.
- Never use a wire.
2. Inspect:
- Main jet (1)
- Pilot jet (2)
- Needle jet (9)
- Pilot screw (7)
- Starter jet (3)
- Main air jet (4)
- Pilot air jet (8)
Damage: Replace
Contamination: Clean
NOTE:
- Use a petroleum based solvent for cleaning. Blow out all pas-
sages and jets with compressed air.
- Never use a wire.
