M.29Part. N. 8000 H1344 (10-2009)
ELECTRIC SYSTEM, DIGITAL INSTRUMENT
Rear tail light bulb replacement (TE 310 EU)
To gain access to the tail light bulb (12V-5/21W), proceed as follows:
- remove the two fastening screws (1) and the rear lens (2);
- pull the lamp (3) inside, turn it counterclockwise then remove it from the lamp
holder.
After replacement, reverse operations for reassembly.
Make sure not to tighten the screws excessively.
