F.16 Part. N. 8000 H1344 (10-2009)
ENGINE DISASSEMBLY
Electric starting system disassembly (TE, TXC; SMR 450-510)
Remove the four fastening screws (8 mm wrench) and starting gears retaining
plate.
Extract the starting gear and starting idle gear.
