I.13
Part. N. 8000 H1344 (10-2009)
FRONT SUSPENSION
BRAKING DOWN THE PUMPING ELEMENT AND THE BOTTOM VALVE
WARNING
This operation must be done only after having drained all of the oil
out of the fork leg.
the body rotation; to do so, the slot obtained at the tooling lower edge must be
perfectly inserted into the body hexagon.
WARNING
In the tooling upper part there are two opposite holes where you can
insert an axle to make the blocking easier. However, the tooling must
not be rotated in any case, but only used to hold the fork leg inner parts.
