F.17Part. N. 8000 H1344 (10-2009)
ENGINE DISASSEMBLY
Remove the two fastening screws (8 mm wrench) and extract the starting mo-
tor.
Oil pump disassembly
Using pointed pliers, remove the oil pump idle gear circlip, then the idle gear.
Remove the three fastening screws (8 mm wrench) and extract: the oil pump
body, the gasket, the two bushes and the oil pump.
