SETTINGS AND ADJUSTMENTS
Part. N. 8000 H1344 (10-2009) D.15
Checking the engine oil level
By keeping the motorcycle on a at surface, in vertical position, remove the
control screw (1) and check the oil should just barely escape from the hole on
the R.H. cover. To ll up, remove the ller cap (2).
: Have this operation made with warmed-up engine.
: Be careful not to touch hot engine oil.
MAX
MIN
1
2
