Husqvarna TE 310 - Clutch Discs Replacement (TC-TE-TXC-SMR)

D.10 Part. N. 8000 H1344 (10-2009)
SETTINGS AND ADJUSTMENTS
1
Clutch discs replacement (TC-TE-TXC-SMR)
This operation can be carried out by laying the motorcycle on the left side without
draining the engine oil. Remove the ve fastening screws (1) and the clutch
cover (if necessary, lower the rear brake control pedal). Use a 5 mm allen wrench
to loosen the six screws (2) that fasten clutch springs. Remove springs, pressure
plate (3) complete with bearing and clutch control rod (4). Extract the discs (5),
lubricate the new discs with engine oil then assemble the new discs (rst always
mount a lined disc). Reassemble pressure plate and springs. Tighten the clutch
springs bolts whilst following a cross-over pattern and in steps (8 Nm-0,8 Kgm-
5.8 ft/lb). Reassemble the clutch cover (8 Nm-0,8 Kgm- 5.8 ft/lb).
