I.12
Part. N. 8000 H1344 (10-2009)
FRONT SUSPENSION
Draining the oil
WARNING
This operation cannot be carried out with the fork installed on the motorcycle.
We recommend loosening the fork cap a little before removing the fork
leg from the fork yokes.
motorcycle owner’s manual.
can reach the locknut ( 23 ) with the 19 mm spanner.
unscrew the fork cap ( 48 ) completely.
the preload tube ( 25 ).
The R5051AC is available as spare part: if you tighten it on the rod’s edge,
you can make the rod extraction from the inner part of the slider easier.
oil seal and guiding elements condition. If the oil is dense and dark with
solid particles in it, you will have to replace the guide bushings and the
sealing elements.
Paragraph 4.11 describes the procedure for
84
13
02
12
23
52
