Husqvarna TE 310 - Brakes; Frame; Suspensions; Tires

A.6 Part. N. 8000 H1344 (10-2009)
GENERAL
FRAME
Steel single tube cradle (round, rectangular and ellipsoidal tubes, branching off into two parts approximately at the exhaust level),
rear frame in light alloy
Forward travel (in.) .............................................................. 4.17 (TE-TXC); 4.10 (TC); 3.27 (SMR)
SUSPENSIONS
Front
“KAYABA” (TE, TXC 450-510, TC 450) or “MARZOCCHI” (TE 310/EU, SMR 450-510) overturned forkrod telehydraulic fork with ad-
vanced pin; forkrods 1.97 in. diameter (TE, TXC 450-510, TC 450) or 1.89 in. (TE 310/EU, SMR 450-510); hydraulic brake adjustment
both in compression and extension
Axle travel on leg axis (in.) .................................................. 11.81 (TE, TC, TXC); 9.84 (SMR)
Rear
Swinging arm in light alloy with progressive damping, “SACHS” hydraulic mono-shock absorber with helical spring.
Hydraulic brake and spring preloading adjustment both in compression (DOUBLE) and in extension.
Wheel travel (in.) ................................................................. 11.65 (TC-TXC-TE); 11.41 (SMR)
BRAKES
Front
Drilled xed disc 10.24 in. dia. “wave” type, with oating caliper (TE, TC, TXC); drilled oating disc 12.6 in. dia. (SMR) with radial xed
caliper
Pads area ........................................................................... 5.18 sq. in. (TE, TC); 6.48 sq. in. (SMR)
Independent hydraulic circuit and pump with control on the handlebar right side
Rear
Floating drilled disc 9.45 in. (“wave” type for TE and TC), with oating caliper
Pads area ........................................................................... 3.64 sq. in.
Independent hydraulic circuit; controlled by pedal and pump on the motorcycle right side.
WHEELS
Rims
Front (TE, TXC) ................................................................. "TAKASAGO“ Excel in lega leggera: 1,6x21”
Front (SMR) ....................................................................... "SANREMO" in light alloy: 3.50x17”
Rear (TE, TXC) .................................................................. "TAKASAGO“ Excel in light alloy: 2.15x18”
Rear (TC) ........................................................................... "TAKASAGO“ Excel in light alloy: 2.15x19”
Rear (SMR) ....................................................................... "SANREMO" in light alloy: 4.25x17”
TIRES
Front
(TE-TXC) ........................................ "Michelin" ENDURO COMP. 3 - "Pirelli" MT 83 Scorpion; 90/90x21"
(TC) ................................................ "Pirelli" 51R-MT 32A - Dunlop D756; 80/100 x 21”
(SMR) ............................................. "Pirelli" MTR 21 DRAGON-EVO; 120/70-17”
Rear
(TE-TXC) ......... ..........................."Michelin" ENDURO COMP. 3 - "Pirelli" MT 83 Scorpion; 120/90x18” (310) - 140/80x18” (450-510)
(TC) ................. ........................... "Pirelli" NHS (62) MT 32; 110/90x19”
(SMR) .............. ..........................."Pirelli" MTR 22 DRAGON-EVO; 150/60x17”
Cold tire pressure (front TE-TXC racing use, TC) .......................... 0.9÷1.0 Kg/cm
2
(12.8-14.2 psi)
Cold tire pressure (rear TE-TXC racing use, TC) ........................... 0.8÷0.9 Kg/cm
2
(11.4-12.8 psi)
Cold tire pressure (front TE-TXC road use) ................................... 1.1 Kg/cm
2
(15.6 psi)
Cold tire pressure (rearTE-TXC road use) ..................................... 1.0 Kg/cm
2
(14.2 psi)
Cold tire pressure
(front SMR) ........................................................ 1.4 kg/cm
2
- 20 p.s.i.(Racing use); 1.8 kg/cm
2
- 25.6 p.s.i. (Road use: rider only);
............................................................................ 2.0 kg/cm
2
- 28.4 p.s.i. (Road use: rider and passenger)
Pressione di gonaggio a freddo
(rear SMR) .......................................................... 1.6 kg/cm
2
- 22.7 p.s.i. (Racing use); 2.0 kg/cm
2
- 28.4 p.s.i. (Road use: rider only);
............................................................................ 2.2 kg/cm
2
- 31.3 p.s.i. (Road use: rider and passenger)
