H.20 Part. N. 8000 H1344 (10-2009)
ENGINE REASSEMBLY
Reassembly of crankcase
Clean the faces between the half-cases then support the half-case using a suit-
able tool code no. 8A00 90662.
Install the two gearbox shafts as one unit.
Warm up at approx. 125°C (257°F), and t the ball bearings into the two half-
cases with a suitable tool (crankcase bearings plates screws: 11Nm/ 1,1 Kgm/
7.9 ft-lb + LOCTITE 272).
Install the three gear strikers.
