A.7Part. N. 8000 H1344 (10-2009)
GENERAL
ELECTRICAL COMPONENTS LOCATION (TE-SMR)
The ignition system includes the following elements:
- Generator, in oil bath, on the inner side of L.H. crankcase cover;
- Electronic ignition coil under the fuel tank;
- Electronic power unit C.D.I. under the fuel tank;
- Voltage regulator under the fuel tank;
- Spark plug on the R.H. side of cylinder head;
- Starting motor 12V-450W behind the cylinder;
- Electric start remote control switch on the left side of the rear frame.
- M.A.Q.S. sensor (pressure, throttle control position, air temperature) on the throttle body.
The electric system includes the following elements:
- Battery 12V-6Ah or, in alternative, 12V-7Ah, under the saddle;
- Flashing indicator device on the left side of the rear frame;
- Relay for light and injection system, on the L.H. side of the frame;
- Relay for the electric fan, on the R.H. side of the frame;
- Electric fan;
- Two fuses 15A and one 20A, on the right side of the rear mudguard;
- Fall sensor on the right side of the rear frame;
- Coolant temperature sensor;
- Lambda probe;
- Headlamp with two laments bulb of 12V-35/35W and parking light bulb of 12V-3W;
- Rear tail-light LED type (Excluded TE 310/EU);
- Rear tail-light with stop bulbs of 12V-21W and parking light bulb of 12V 5W (Only TE 310/EU);
- Turn signals bulb of 12V-10W;
- Fuel pump inside the fuel tank.
ELECTRICAL COMPONENTS LOCATION (TC-TXC)
The ignition system includes the following elements:
- Generator on the inner side of L.H. crankcase cover;
- Electronic coil and condenser (TXC) under the fuel tank;
- Electronic power unit C.D.I. under the fuel tank;
- Voltage regulator under the fuel tank;
- Spark plug on the R.H. side of cylinder head;
- Starting motor 12V-450W behind the cylinder (TXC);
- Electric start remote control switch on the left side of the rear frame (TXC);
- Potentiometer on the carburettor.
The electric system includes the following elements (TXC):
- Battery 12V-6Ah under the saddle;
- Two fuses 20A, on the electric starter contactor.
