F.19Part. N. 8000 H1344 (10-2009)
ENGINE DISASSEMBLY
Remove the gear shifter drum fastening bolt (5 mm wrench).
Remove the fastening screw and the gears pawl together with its spring. Pay
attention for not to lose the roller.
