H.9Part. N. 8000 H1344 (10-2009)
ENGINE REASSEMBLY
Tightening torques
8 M18x1,25 180 Nm- 18 Kgm- 130 ft/lb
11 M6x1 (+LOCTITE 272) 11 Nm- 1,1 Kgm- 7.9 ft/lb
14 M6x1 8 Nm- 0,8 Kgm- 5.8 ft/lb
20 M18x1 75 Nm- 7,6 Kgm- 55 ft/lb
21 M6x1 (+LOCTITE 243) 11 Nm- 1,1 Kgm- 7.9 ft/lb
22 M10x1,25 (+LOCTITE 601) 15 Nm- 1,5 Kgm- 10.8 ft/lb
STANDARD
M5x0,8 6 Nm- 0,6 Kgm- 4.3 ft/lb
M6x1 8 Nm-0,8 Kgm- 5.8 ft/lb
M8x1,25 21 Nm- 2,1 Kgm- 15.5
ft/lb
LUBRICATING POINTS-NOTES LUBRICANT-INSTRUCTIONS FOR ASSEMBLY
C Glue the two half casings by “Loctite 510" (Pianermetic)
O Engine oil
O/G Engine oil or grease WATER RESISTANT
