• Push the pre- assembled pumping element ( 23 ) until it is in contact with the
stanchion tube ( 5 ).
body rotation; to do so, the slot obtained at the tooling bottom edge must be
perfectly inserted into the body hexagon.
WARNING
In the tooling upper part there are two opposite holes where you can
insert an axle to make blocking easier. However, the tooling must not
be rotated in any case, but only used to hold the fork leg inner parts.
