I.36
Part. N. 8000 H1344 (10-2009)
FRONT SUSPENSION
Push the inner tube downwards.
Position the tool illustrated between the wheel pin support and the nut of the
cartridge unit.
Insert the inner push rod into the piston rod and tighten the adjusting screw.
Tighten the adjusting screw fully.
Make sure there is play between the lower part of the adjusting screw and the
upper edge of the nut.
With a screwdriver, tighten the nut and the adjusting screw to 28 Nm (20.6 ft/lb).
