BRAKES
1. Front brake control lever
2. Front brake pump with oil reservoir (TE, TC)
2. Front brake pump (SMR)
2A. Oil reservoir (SMR)
3. Front brake hose
4. Front brake caliper
5. Front brake disc
6. Rear brake oil tank
7. Rear brake hose
8. Rear brake caliper
9. Rear brake disc
10. Rear brake pump
11. Rear brake control pedal
BRAKING SYSTEM
The braking systems is divided into two completely independent circuits.Each system is provided with a caliper connected to a hydraulic
control pump with tank for the uid.
SMR
TC-TXC
2A
11
6
10
