M.37Part. N. 8000 H1344 (10-2009)
ELECTRIC SYSTEM, DIGITAL INSTRUMENT
The instrument display shows even then informations of the “Neutral” condi-
tion and of any possible “Malfunction” of the FUEL INJECTION SYSTEM; this
last condition is showed with absolute priority with respect to any other
information.
NEUTRAL: if the speed is under 20 Km/h (12,5 mph), the “Neutral” condition the
instrument displays the N character before the value of the speed.
MALFUNCTION: in case of FUEL INJECTION SYSTEM malfunction on the right
side of the instrument display will be displayed the warning message “FAIL”.
TE
SMR
A
A
Instructions for the instrument setting
Upon turning on the instrument, if the operation DID NOT already take place,
it is necessary to set the instrument associating it with the relative motorcycle
by selection of the codes illustrated in the gures shown.
The identication codes appear on the display of the instrument at 2 second
intervals: when the required code appears, press the button (A) on the
instrument.
BE VERY CAREFUL WHEN SELECTING. THE OPERATION CAN
ONLY BE EXECUTED ONCE.
