M.41Part. N. 8000 H1344 (10-2009)
ELECTRIC SYSTEM, DIGITAL INSTRUMENT
• Injection central unit positioning
Injection central unit installed with at side downward.
• Remote control switch positioning
Install the remote control switch as shown.
• Positioning the voltage rectier
Voltage regulator with dissipation plate covered in thermal grease
.
• Fastening the starter motor-remote control switch cable
Connect the starter motor-remote control switch cable as shown in the picture.
