O.26 Part. N. 8000 H1344 (10-2009)
“KIT” ASSEMBLING INSTRUCTIONS
Identify the cover of the throttle cable pulley of the throttle body located on the
right side of the vehicle.
Move away the pedal starting lever from the pulley cover.
Loosen the hexagonal socket screw holding the plastic cover.
Remove the screw.
Remove the cover of the throttle cable pulley.
Throttle body plate removal
