IAI PCON-CB series User Manual

4. Operation
4.3 Pulse Train Control Mode
4-118
ME0342-4B
[2] Position Complete (INP)
PIO signal
Output
INP
This signal will turn ON when the remaining travel pulses (accumulated pulses) on the deviation
counter enters the positioning width.
When the servo is ON, this signal turns ON when the accumulated pulses on the deviation
counter are within the number of pulses set in Parameter No.10 “Default positioning width”.
This signal is OFF while the servo is OFF.
Caution
● This signal will turn ON when the servo turns ON (because positioning is executed at
the current position where the servo is ON).
● This signal turns on in response to the deviation (servo lag pulses) and the variance to
the command pulse in 1ms.
Even if the deviation is within the positioning width, the signal would not turn on if there
is a variance to the command pulse in 1ms.
[3] Torque Limit Select (TL, TLR)
PIO signal
Input
Output
TL
TLR
This signal is used to limit the torque of the motor.
While the TL signal is ON, the actuator thrust (motor torque) can be limited to the torque set in
Parameter No.57 “Torque limit”.
With the TL signal being ON, the TLR signal (torque limiting) will turn ON when the actuator
thrust reaches the torque limit.
The TL signal is disabled during home return or forced stop.
Caution
● Do not turn the TL signal OFF while the TLR signal is ON.
● An excessive deviation (accumulated pulses) may generate while torque is being limited
(TL signal is ON) (for example, the actuator may receive a load just like it receive a
pressing force in pressing operation and therefore become no longer operable). If the
TL signal is turned OFF in this condition, actuator control will start at the maximum
torque the moment the signal changes, thus causing the actuator to move suddenly or
run uncontrollably.
After turning TLR signal ON, perform an operation in the reversed way to confirm TLR
signal turns OFF. If the condition is difficult for the reversed movement, turn the servo
OFF or clear the deviation counter (by turning DCLR ON).
4.3 Pulse Train Control Mode
ME0342-4B 4-119
[4] Deviation Counter Clear (DCLR)
PIO signal
Input
DCLR
This is the signal to clear the deviation counter that stores the specified pulse until its process is
completely finished (positioning is completed) once a command pulse is input.
It is used when the deviation is desired to be cleared after the pressing by TL signal is complete
(TLR signal ON). Once the deviation is cleared, TLR signal turns OFF and the condition can be
made as it is positioned at the point where the pressing is complete.
Caution
● DCLR signal is a signal that is processed at the startup (ON edge). Therefore, input the
pulse train while DCLR signal is on and the actuator will operate. Turn this signal ON
only when the deviation counter is to be cleared.
