9. Appendix
9.2 Conformi
ty to Saf
ety Category
9-20
ME0342-4B
[3]
Dummy plug
Connect a dummy
plug to the teaching pend
ant connecting c
onnector
.
Make sure to connec
t a dummy plug if the
AUTO mode is specified.
Without the connecti
on, it will be the emergenc
y stop conditi
on.
Model : DP
-
4S
DP
-
4S
Plug : HDR
-
E26MAG1+
Short
-
circuit
processi
ng
Signal
No.
GND
1
EMGS
2
VCC
3
DTR
4
EMGOUT2
5
EMGIN2
6
NC
7
RSVCC
8
EMGIN1
9
NC
10
NC
11
EMGOUT1
12
RTS
13
CTS
（
GND
）
14
TXD
15
RXD
16
DSR
17
NC
18
NC
19
RSVTBX1
20
RSVTBX2
21
ENBVCC2
22
ENBTBX1
23
ENBVCC1
24
ENBTBX2
25
GND
26
403
405
