9. Appendix
9.4 List of Specifications of Connectable Actuators
9-70 ME0342-4B
RCP2 Series
Actuator
series
Type
Feed
screw
No. of
encoder
pulses
Lead
[mm]
Mounting
direction
Minimum
speed
[mm/s]
Maximum speed
[mm/s]
Maximum acceleration
/deceleration
[G]
Minimum
push force
[N]
Maximum
push
force
[N]
Rated push
speed
[mm/s]
RCP2
(Slider
type)
SA7C
Ball
screw
800
16
Horizontal
20
533 (at 50 to 700st)
480 (at 800st)
0.3
90 250
20
Vertical
0.2
8
Horizontal
10
266 (at 50 to 700st)
240 (at 800st)
0.3
150 500
Vertical
0.2
4
Horizontal/
vertical
5
133 (at 50 to 700st)
120 (at 800st)
0.2 280 800
SA7R
Ball
screw
800
16
Horizontal
20
533 (at 50 to 700st)
480 (at 800st)
0.3
- - -
Vertical
400
0.2
8
Horizontal
10
266 (at 50 to 700st)
240 (at 800st)
0.3
- - -
Vertical
0.2
4
Horizontal/
vertical
5
133 (at 50 to 700st)
120 (at 800st)
0.2
SS7C
Ball
screw
800
12
Horizontal
15
600 (at 50 to 500st)
470 (at 600st)
0.3
40 115
20
Vertical
0.2
6
Horizontal
8
300 (at 50 to 500st)
230 (at 600st)
0.3
70 210
Vertical
0.2
3
Horizontal/
vertical
4
150 (at 50 to 500st)
115 (at 600st)
0.2 140 330
SS7R
Ball
screw
800
12
Horizontal
15
600 (at 50 to 500st)
470 (at 600st)
0.3
- - -
Vertical
440
0.2
6
Horizontal
8
250 (at 50 to 500st)
230 (at 600st)
0.3
Vertical
0.2
3
Horizontal/
vertical
4 105 0.2
SS8C
Ball
screw
800
20
Horizontal
25
666 (at 50 to 800st)
625 (at 900st)
515 (at 1000st)
0.3
50 180
20
Vertical
600 (at 50 to 900st)
515 (at 1000st)
0.2
10
Horizontal
13
333 (at 50 to 800st)
310 (at 900st)
255 (at 1000st)
0.3
95 320
Vertical
300 (at 50 to 900st)
255 (at 1000st)
0.2
5
Horizontal
7
165 (at 50 to 800st)
155 (at 900st)
125 (at 1000st)
0.2 180 630
Vertical
150 (at 50 to 900st)
125 (at 1000st)
SS8R
Ball
screw
800
20
Horizontal
25
600 (at 50 to 900st)
515 (at 1000st)
0.3
- - -
Vertical
333
0.2
10
Horizontal
13
300 (at 50 to 900st)
255 (at 1000st)
0.3
Vertical
250
0.2
5
Horizontal
7
160 (at 50 to 800st)
155 (at 900st)
125 (at 1000st)
0.2
Vertical
140
HS8C
HS8R
Ball
screw
800 30
Horizontal
100
1200 (at 50 to 800st)
1000 (at 900st)
800 (at 1000st)
0.5
- - -
Vertical
750
0.2
