9. Appendix

9.4 List of Specifications of Connectable Actuators

9-130 ME0342-4B

RCP6 Series (Gripper type)

GRST7C/GRST7R

Current-limiting value (%)

Gripping force (N)

Lead 8

Current-limiting value (%)

Gripping force (N)

Lead 2
