3. Wiring
3.1 Positioner Mode (PIO Control)
3-3
ME0342-4B
Pin
No.
Category
PIO Functions
Parameter No.25 “PIO Pattern Selection
4
5
6
(Note 2)
7
(Note 2)
Solenoid Valve
Mode 1
Solenoid Valve
Mode 2
Force Sensor Used
Pressing Mode 1
Force Sensor Used
Pressing Mode 2
Input
Number of positioning
points
7 points 3 points 32 points 5 points
Home return signal
×
Jog signal
×
×
×
×
Teaching signal
(Current position
writing)
× × × ×
Brake release
Output
Moving signal
×
×
×
×
Zone signal
(Note 1)
(Note 1)
Position zone signal
1A
24V
P24
2A
24V
P24
3A
Pulse
input
4A
5A
Input
IN0
ST0
ST0
PC1
ST0
6A
IN1
ST1
ST1(JOG+)
PC2
ST1
7A
IN2
ST2
ST2
(Note 3)
PC4
ST2
8A
IN3
ST3
PC8
ST3
9A
IN4
ST4
PC16
ST4
10A
IN5
ST5
11A
IN6
ST6
12A
IN7
13A
IN8
CLBR
CLBR
14A
IN9
BKRL
BKRL
BKRL
BKRL
15A
IN10
RMOD
RMOD
RMOD
RMOD
16A
IN11
HOME
HOME
HOME
17A
IN12
*STP
*STP
*STP
18A
IN13
CSTR
19A
IN14
RES
RES
RES
RES
20A
IN15
SON
SON
SON
SON
1B
Output
OUT0
PE0
LS0
PM1(ALM1)
PE0
2B
OUT1
PE1
LS1(TRQS)
PM2(ALM2)
PE1
3B
OUT2
PE2
LS2
(Note 3)
PM4(ALM4)
PE2
4B
OUT3
PE3
PM8(ALM8)
PE3
5B
OUT4
PE4
PM16
PE4
6B
OUT5
PE5
TRQS
TRQS
7B
OUT6
PE6
LOAD
LOAD
8B
OUT7
ZONE1
ZONE1
CEND
CEND
9B
OUT8
(Note 1)
PZONE/ZONE2
PZONE/ZONE2
PZONE/ZONE2
PZONE/ZONE2
10B
OUT9
RMDS
RMDS
RMDS
RMDS
11B
OUT10
HEND
HEND
HEND
HEND
12B
OUT11
PEND
PEND
PEND
13B
OUT12
SV
SV
SV
SV
14B
OUT13
*EMGS
*EMGS
*EMGS
*EMGS
15B
OUT14
*ALM
*ALM
*ALM
*ALM
16B OUT15
LOAD/TRQS
*ALML
*ALML *ALML *ALML
17B
Pulse
input
18B
19B
0V
N
20B
0V
N
(Note) “*” in codes above shows the signal of the active low.
PM1 to PM8 indicate the alarm binary code output signal when an alarm is generated.
Refer to [4.2.4 [7] Binary Output of Alarm Data Output]
(Note 1) The mode can be switched over to PZONE with the setting of Parameter No.149 except for PIO Pattern 3.
(Note 2) PIO Patterns 6 and 7 should be available only when PCON-CBP/CGBP are ordered at purchasing.
(Note 3) It is invalid before home-return operation.
3.1 Positioner Mode (PIO Control)
ME0342-4B 3-4
(Reference) Signal of Active Low
Signal with “*” expresses the signal of active low. A signal of active low is a signal that the input
signal is processed when it is turned OFF, output signal is ordinarily (or just omit) on while the
power is ON, and turns OFF when the signal is output.
