3. Wiring
3.1 Positioner Mode (PIO Control)
3-7
ME0342-4B
S1
S2
MPI
MPO
24V
0V
24V
0V
EMG-
BK
Power Supply
Connector
Emergency-stop
Switch on the
Teaching Pendant
Control
Power
Supply
SIO Connector
PCON
Wiring Condected
at Delivery
24V DC
Power Supply
Motor Power Supply
Emergency Stop Control Circuit
Brake Release Power Supply
(Note) Supply 24V when connecting actuator
equipped with brake and release brake
compulsorily
Drive Cutoff
Circuit
The emergency stop
switch is activated.
please prepare
separately)
3.1.3 Wiring
[1] Power Supply Connector (for Power Supply and Emergency Stop)
As an example of a circuit, cases of 4 conditions are shown. Select from 3) or 4) for CGB type.
1) Activate the stop switch on the teaching pendant to activate an actuator
● Example of Circuit
The emergency stop input to the controller gets inactivated by supplying +24V continuously to
EMG- Terminal. +24V is connected to EMG- via the emergency stop switch on the teaching
pendant.
● Image of Wiring
3.1 Positioner Mode (PIO Control)
ME0342-4B 3-8
Caution
● When supplying the power by turning ON/OFF the 24V DC, keep the 0V being
connected and have the +24V supplied/disconnected (cut one side only). Shutting
power supply on the both ends may make the electric potential unstable when the
power gets cut on the 0V end first. This may cause malfunction of components inside
the controller.
● The rating for the emergency stop signal (EMG-) is 24V DC and 10mA or less.
● Leave for 1s or more after shutting the power off before rebooting.
● Do not attempt to supply only the motor power without supplying the control power.
● There could be a case that the voltage supplied to the controller drops due to cable
diameter or length, which may generate an alarm. In this case, it is necessary to adjust
the output voltage on the power so the voltage supplied to the controller gets to 24V.
To Next Page
