Server Chassis P4304XXMFEN2/P4304XXMUXX Product Family System Integration and Service Guide
144
Color
State
Criticality
Description
impending failure
warning, although
still functioning
Minimum number of fans to cool the system not present or failed
Hard drive fault.
Power Unit Redundancy sensor – Insufficient resources offset (indicates
not enough power supplies present).
In non-sparing and non-mirroring mode if the threshold of correctable
errors is crossed within the window.
Amber
Solid on
Critical, non-
recoverable –
System is halted
Fatal alarm – system has failed or shut down.
CPU CATERR signal asserted.
MSID mismatch detected (CATERR also asserts for this case).
CPU 1 is missing.
CPU Thermal Trip.
No power good – power fault.
DIMM failure when there is only 1 DIMM present and hence no good
memory present.
Runtime memory uncorrectable error in non-redundant mode.
DIMM Thermal Trip or equivalent.
SSB Thermal Trip or equivalent.
CPU ERR2 signal asserted.
BMC/Video memory test failed. (Chassis ID shows blue/solid-on for this
condition).
Both uBoot BMC FW images are bad. (Chassis ID shows blue/solid-on
for this condition).
240VA fault.
Fatal Error in processor initialization:
Processor family not identical
Processor model not identical
Processor core/thread counts not identical
Processor cache size not identical
Unable to synchronize processor frequency
Unable to synchronize QPI link frequency
Uncorrectable memory error in a non-redundant mode.
