Server Chassis P4304XXMFEN2/P4304XXMUXX Product Family System Integration and Service Guide
26
Figure 31. Processor Heat Sink
CAUTION: Do not touch sensitive contacts on the bottom side of the processor at any time during PHM
assembly or installation. Also refrain from touching the pins inside the processor socket as they also are
extremely sensitive. A damaged processor socket may produce unpredictable system errors.
2. If it is present, carefully remove the plastic protective cover from the bottom side of the
processor.
