Diagnostic LED Decoder
LED
#
LED 3 LED 2 LED 1 LED 0
Description
Checkpoint
Upper
Nibble
8h
(MSB)
4h 2h
1h
(LSB)
Lower
Nibble
8h
(MSB)
4h 2h
1h
(LSB)
Lower
Nibble
ON off ON ON
03h = Hardware Mem-test failure in Lockstep Channel
mode, requiring a channel to be disabled.
This is a fatal error which requires a reset and calling MRC
with a different RAS mode to retry.
EDh
Upper
Nibble
ON ON ON off
DIMM configuration population error
01h = Different DIMM types (UDIMM, RDIMM, LRDIMM) are
detected installed in the system.
02h = Violation of DIMM population rules.
Lower
Nibble
ON ON off ON
03h = The 3rd DIMM slot cannot be populated when QR
DIMMs are installed.
04h = UDIMMs are not supported in the 3rd DIMM slot.
05h = Unsupported DIMM Voltage.
EFh
Upper
Nibble
ON ON ON off
Indicates a CLTT table structure error
Lower
Nibble
ON ON ON ON
BIOS POST Progress Codes
The following table provides a list of all POST progress codes.
Table 12. POST Progress Codes
Diagnostic LED Decoder
LED #
LED 3 LED 2 LED 1 LED 0
Description
Checkpoint
Upper Nibble
8h
(MSB)
4h 2h
1h
(LSB)
Lower Nibble
8h
(MSB)
4h 2h
1h
(LSB)
SEC Phase
