Hardware Installations and Upgrades
Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide (Preliminary) 97
2. Effective Memory
Option Values: <Total Effective Memory>
Help Text: <None>
Comments: Information only
. Displays the amount of memory available to the OS in
MB or GB.
The Effective Memory is the Total Physical Memory minus the sum of all memory reserved for
internal usage, RAS redundancy and SMRAM.
/
NOTE
Some server operating systems do not display the total physical memory installed.
Back to [Memory Configuration Screen] — [Advanced Screen]
3. Current Configuration
Option Values: Independent Channel
Mirror
Rank Sparing
Lockstep
Help Text: <None>
Comments: Information only
: Displays one of the following:
Independent Channel – DIMMs are operating in Independent Channel Mode, the
default configuration when there is no RAS Mode configured.
Mirror – Mirroring RAS Mode has been configured and is operational.
Rank Sparing – Rank Sparing RAS Mode has been configured and is operational
Lockstep – Lockstep RAS Mode has been configured and is operational
Back to [Memory Configuration Screen] — [Advanced Screen]
4. Current Memory Speed
Option Values: <Operational Memory Speed in MT/s>
Help Text: <None>
Comments: Information only
. Displays the speed in MT/s at which the memory is
currently running.
The supported memory speeds are 800 MT/s, 1066 MT/s, 1333 MT/s, and 1600 MT/s. The actual
memory speed capability depends on the memory configuration.
Back to [Memory Configuration Screen] — [Advanced Screen]
