1.3 Composition
Composition of the Radar and Ship Internal Power Source
Comprehensive type Scanner unit Display unit Ship internal power source
JMA-2343
JMA-2344
NKE-249
NKE-250
NCD-4170
DC (12V/24V/32V)
or
AC
(Note)
(100V/110V/115V/
200V/220V/230V)
50/60Hz single phase
Rectifier type (option) NBA-797
(Note) When AC power source is used, the optional rectifier is required.
Accessories
Product Name Quantity JRC Code Remarks
Instruction Manual 1 7ZPRD0558 This manual
CFQ6774-15
(JMA-2343)
10 core composite cable
15m
Cable between the scanner
unit and display unit
1
CFQ6882-20
(JMA-2344)
14 core composite cable
20m
Power cable assembly 1 CFQ-6776 2m
Sun shield 1 MTV303344 －
Standard spare parts kit (7ZXRD0008)
Product name (type) Quantity JRC Code Remarks
Fuse (SB3.15) 2 5ZFAD00382 (for 24/32V) 3.15A
Fuse (SB6.3) 3 5ZFAD00540 (for 12V) 6.3A
Fuse (SB5) 2 5ZFAD00364 (for 24/32V) 5A
Fuse (SB10) 3 5ZFAD00539 (for 12V) 10A
Optional
Product Name Quantity JRC Code Remarks
CFQ6774-10
(JMA-2343)
10 core composite cable
10m
CFQ6774-20
(JMA-2343)
10 core composite cable
20m
CFQ6882-10
(JMA-2344)
14 core composite cable
10m
Cable between the scanner
unit and display unit
1
CFQ6882-15
(JMA-2344)
14 core composite cable
15m
Plug side connector (for J3) 1 5JCDX00014 －
Plug side connector (for J4) 1 5JCDX00015 －
